Surface Contours
00000000-c898-4c23-8494-10e30d8087c6
object preview
This page was generated from the component’s built-in descriptions. An in-depth article has not been written for it yet.

Create a set of equally spaced surface contours.

Input parameters:

  1. Sf → Surface to contour.
  2. Pt → Contour base point
  3. Nr → Contour slice normal direction.
  4. Sp → Spacing between contour layers.

Output parameters:

  1. Ct → Contour curves, sorted by layer
  2. Ly → Layer, i.e. contour section offset, given as an integer. Layer zero is the section through the base point.
