Draft Angle Display
00000000-60aa-4714-8919-2c7fec7a7e1d
object preview
This page was generated from the component’s built-in descriptions. An in-depth article has not been written for it yet.

Display the draft angle analysis of a surface.

Input parameters:

  1. Sh → Surface or mesh to analyse.
  2. Up → Up direction.
  3. Gr → Visualisation gradient, parameterised to degrees.

Output parameters:

  1. Ms → Mesh with analysis colours.
