Custom Rectangle Grid
00000000-2883-48ff-b86e-650abfeba82a
object preview
This page was generated from the component’s built-in descriptions. An in-depth article has not been written for it yet.

Generate a two-dimensional grid consisting of custom spaced perpendicular lines.

Input parameters:

  1. Pl → Grid origin and orientation plane.
  2. Tx → Transitions between adjacent columns in the grid.
  3. Ty → Transitions between adjacent rows in the grid.

Output parameters:

  1. Pt → Points on the grid. Point structuring (flat, rows, or columns) can be modified from the component menu.
  2. Cl → Grid cell outlines. Cell structuring (flat, rows, or columns) can be modified from the component menu.
  3. Lx → Lines in the grid X direction.
  4. Ly → Lines in the grid Y direction.
