InflateCrv

InflateCrv

Give curves a dimensional, puffy look with just a few clicks.

A True Time-Saver

InflateCrv quickly transforms closed curves into smooth, inflated forms, giving you control over thickness and corner softness. It’s an easy way to move from flat profiles to dimensional geometry, providing that “puffy” look without complex surfacing.

Draft Angle

The DraftAngle setting can help to speed up production by minimizing 3D printer supports, as well as allowing parts to release from molds with ease.

Wide Range of Applications

From jewelry and sign making, to inflatables and packaging, InflateCrv can save a considerable amount of modeling time.

Try it

  1. Download Rhino 9 WIP for Windows or Mac.
  2. Download and open the InflateCrv-Example.3dm model.
  3. Run the InflateCrv command.
  4. Window select the curves and press Enter.
  5. In the Command Prompt , set the:
    1. Height to 5. Press Enter.
    2. Flattenning to 0.2. Press Enter.
    3. Select the Flip option to change the direction of the geometry if need be.
    4. Set Quad Remesh to Yes.
    5. Set Output to SubD.
    6. Press Enter to end the command.
  6. Try it on your own! Experiment with your own examples.
  7. Please provide feedback or ask questions on the Rhino Forum.
